Gold Plated SH3.5-M Connector With Protective

Short Description:


Product Detail

Product Tags

Product Parameter

Product Model: SH3.5-M

Rated Current: 30A MAX(14AWG△<85℃)

Voltage Resistance: 500V DC

Insulation resistance: ≥2000MΩ

Contact resistance: ≤1.0MΩ

Mechanical life: 100times

Salt Spray: 48h

Protection level: IP40

Operational Temperature: -20℃~120℃

Flame Retardant Rating: UL94 V-2

Outer Hull: PA, BLACK

Pinhole: Aldary,Elecreoplate: Gold Plating

Product characteristics

1. SH3.5-M is a 180° outgoing welding type assembly single PIN connector, which is a universal product for lithium battery, controller and motor.

2. It is applicable to the wire-to-wire connection of lithium batteries, motors and controllers.

Announcements

When in use, please don’t exceed the rated current and voltage.

Do not use it when external forces are applied to the connector.

Do not use it in a place with high temperature and humidity.

When opening the package, please be careful to avoid deformation, bending, or ejecting of terminals.

Product Drawing

SH3.5-M
SH3.5-M  (2)

Application Areas

2

Telecontrolled aircraft

telecar

Remote control ship

Unicycle

3

Electric vehicle

UAV

Traversal machine

Solar lamp

1

Balancing car

Electric scooter

Solar lamp
