Q25A-1

Short Description:


Product Detail

Product Tags

Product Parameter

Product Model: Q25A

Type:Double Pole,Ring with LED,Maintained

Material:304 stainless steel housing,PA66

Protection level:IP65, IK10, IP40.

Electrical parameters:5A /250VAC

Contact resistance:≤50Ω

Insulation resistance:≥1000MΩ

LED voltage:3V-220V

Service temperature range:-20℃—55℃

Lamp bead life:40,000 hours

Mechanical life:30 times/min,500,000 times

Product characteristics

1. Adopt flame retardant material, safety guarantee, stainless steel shell anticorrosion and dust proof.

2. Contains PC button, silicone waterproof ring, high performance, solid and reliable.

Product Drawing

wps_doc_0
wps_doc_1

Application Areas

The product can be applied to transportation,safety equipment,household appliances,medical equipment, starter,Bathroom, access control.

Package picture

wps_doc_2
wps_doc_4
