WP12-11 Plastic 4 Positions Connector Terminal Push In Jack Spring Load Audio Speaker Terminals Plug Socket Breadboard Clip

Short Description:

Product: Audio Speaker Terminals

Positions: 4/12

Life: 10,000 Cycles

Actuating Force: 1KGF

Rated load: AC 50V 3A

Contact Resistance:≤0.03Ω


Product Detail

Product Tags

Product: Audio Speaker Terminals

Positions: 4/12

Life: 10,000 Cycles

Actuating Force: 1KGF

Rated load: AC 50V 3A

Contact Resistance:≤0.03Ω

Withstand Voltage:AC500V (50HZ)/min

Insulation Resistance:≥100MΩ DC 500V

Operating Temperature:-25°C~+70°C



Packing & Delivery

Packing
1: Neutral packing: Bulking packing in Poly bag +inner box +carton
2: Upon customers' request

Payment & Delivery
Payment: TT,LC, Western Union, Money Gram, PayPal etc., T/T 30% as deposit and the balance before delivery. We'll show you the photos of the products and packages.

Delivery time: 7-10 working days after the payment confirmed.
Shipment: Ship worldwide by sea, air, express delivery, like DHL, UPS, TNT and FEDEX etc.
