XT30PW Female Connector PCB Board For Unicycle
Product Parameter
Product Model: XT30PW-F
Rated Current: 20A MAX（△＜85℃）
Voltage Resistance: 500V DC
Insulation resistance: ≥2000MΩ
Contact resistance: ≤1.2MΩ
Mechanical life: 100times
Salt Spray: 48h
Protection level: IP40
Operational Temperature: -20℃~120℃
Flame Retardant Rating: UL94 V-0
Outer Hull: PA, YELLOW
Pinhole: Aldary，Elecreoplate: Gold Plating
Product characteristics
1. XT30PW-F is a horizontal injection molded 2PIN connector, which provides an integrated solution for the horizontal PCB board with space. In addition, it has a wired plate design and is the size of a dime
2. It is applicable to the wire-to-board or board-to-board connection between lithium batteries and controllers.
Announcements
When in use, please do not exceed the rated current and voltage.
Do not use this produce when external forces are applied to the connector.
Do not use it in an environment with high temperature and humidity.
Be sure be careful to prevent deformation, bending, or ejecting of terminals when opening the package,
Product Drawing
Application Areas
Telecontrolled aircraft
telecar
Remote control ship
Unicycle
Electric vehicle
UAV
Traversal machine
Solar lamp
Balancing car
Electric scooter
Solar lamp
