XT60PW-F Gold Plating Connectors Plug For Unicycle
Product Parameter
Product Model: XT-60PW-F
Rated Current: 35A MAX（△＜85℃）
Voltage Resistance: 600V DC
Insulation resistance: ≥2000MΩ
Contact resistance: ≤1.0MΩ
Mechanical life: 100times
Salt Spray: 48h
Protection level: IP40
Operational Temperature: -20℃~120℃
Flame Retardant Rating: UL94 V-0
Outer Hull: PA, YELLOW
Pinhole: Aldary，Elecreoplate: Gold Plating
Product characteristics
1, XT-60PW female is a horizontal board assembly type 2PIN connector, optional rear cover, for the horizontal space PCB board to provide integrated solutions, according to the current standard components of lithium power plug-in, wire - to - wire design is carried out.
2. It is applicable to the wire-to-board or board-to-board connection between lithium batteries and controllers.
Announcements
When in use, do not exceed the rated current and voltage.
Do not use it when external forces are applied to the connector.
Do not use it in a place with high temperature and humidity.
Please open the package carefully.
Product Drawing
Application Areas
Telecontrolled aircraft
telecar
Remote control ship
Unicycle
Electric vehicle
UAV
Traversal machine
Solar lamp
Balancing car
Electric scooter
Solar lamp
