Yellow XT60H-F Plug Connector With Sheath Housing
Product Parameter
Product Model: XT60H-F
Rated Current: 30A MAX（12AWG△＜85℃）
Voltage Resistance: 500V DC
Insulation resistance: ≥2000MΩ
Contact resistance: ≤1.0MΩ
Mechanical life: 100times
Salt Spray: 48h
Protection level: IP40
Operational Temperature: -20℃~120℃
Flame Retardant Rating: UL94 V-0
Outer Hull: PA, YELLOW, BLACK
Pinhole: Aldary，Elecreoplate: Gold Plating
Product characteristics
1. The XT60H-F is a classic 180° outbound welded injection molded 2PIN connector with a rear cover, which is the standard accessory for lithium power supply today, wired plate design and locking design.
2. It can be used to connect the lithium battery to the controller.
Announcements
When in use, do not surpass the rated current and voltage.
Do not use it when external forces are applied to the connector.
Do not used it in high temperature and humidity.
Connector type precision parts, please open the wrap carefully
Product Drawing
Application Areas
Telecontrolled aircraft
telecar
Remote control ship
Unicycle
Electric vehicle
UAV
Traversal machine
Solar lamp
Balancing car
Electric scooter
Solar lamp
