HV High Voltage Battery Connector 1500V 200A For Energy Storage System

HV High Voltage Battery Connector 1500V 200A For Energy Storage System Featured Image

Short Description:

Product name: Energy Storage Connector

Color: orange/black (color will be delivered randomly, please note if necessary)

Inserting and pulling force: < 100N

Rated voltage: 1500V DC

Insulation resistance: > 2000mΩ

Insulation withstand voltage: 3000V AC

Protection class: IP67(closed state)

Anti-touch: IP2XB

Operating temperature: -40℃~125℃

Send email to us

Product Detail

Product Tags

Note:

1.Please allow ±0-3mm difference due to manual measurement.

2.Due to the effects of shooting, the photos may not reflect the true colors, subject to the actual product. Please make sure you do not mind before you bid. Thank you!

HV(1)

HV (2)(1)

HV3

KCD4-4(1)

KCD4-5(1)

KCD4-6(1)

KCD4-7(1)

KCD4-8(1)
