Plastic Momentary Reset/Self Locking Push Button Switch

Short Description:

Product name:Push Button Switch

Model Number:DS-211 / DS-213 / DS-314 / DS-316 / DS-427 / DS-428 / PB-305A / PB-305B / R13-507 / R16-503A / R16-50B / R16-503AD / R16-503BD

Operation type:self reset / self locking

Key color:red / green / black / yellow / blue / gray

Application: Generally suitable for water dispensers, treadmills, computer speakers, battery cars, motorcycles, toy cars, and some electronic equipment power switches.


Product Detail

Product Tags

Product Name Push Button Switch Operation Type self reset / self locking
Key color red / green / black / yellow / blue / gray Max Voltage 250VAC
Function ON-OFF, OFF-(ON), ON-(OFF) Max Current 1A
Model Number DS-211 / DS-213 / DS-314 / DS-316 / DS-427 / DS-428 /PB-305A / PB-305B /R13-507 / R16-503A / R16-50B / R16-503AD / R16-503BD

Product characteristics

Push button switch refers to the switch that uses the push button to push the transmission mechanism to make the moving contact and the static contact press on or off and realize the circuit exchange. Push-button switch is a kind of main switch with simple structure and wide application. In electrical automatic control circuit, it is used to manually send out control signals to control contactors, relays, electromagnetic starters, etc.

Self Locking:NO,Press power on maintain, one more press power off

Reset: Press Button power on, press off come back to power off

Product drawing

PB-305
DS-211

Application

1. Audio / Video product:MP3, MP4, DVD, stereo system
2. Digital devices: digital camera, digital video
3. Remote control: Vehicle, rolling door, Home security products
4. Communication products: mobiles, car telephone, telephone, building equipment, PDA etc.
5.Household Appliances: TV, microwave oven, electric cooker, electric hair drier, electronic scale, Body Fat &Water Scale, Kitchen Scale.
6. Security Products: Videophone, Monitor etc.
7. Toy: electronic toy etc.
8. Computer products: Camera, recording pen etc.
9. Fitness equipment: running machine, massage chair, timer etc.
10. Medical Equipment: sphygmomanometer, thermometer, the hospital call system and other similar products.
